INON

Underwater Close-up Lens

Underwater Close-up Lens


[ZD Mount]
UCL-G100 ZD Underwater Close-up Lens

JAN/EAN code : 410570018120961

*The packaged Focus Stick is designed for GoPro® cameras.

UCL-G100 ZD Underwater Close-up Lens

Bayonet INON ZD Mount compatible to support friendly and speedy lens exchange underwater. Optional INON ZD Lens Holder can hold the UCL-G100 ZD when the lens is not in use.

Drastically shorten minimum focusing distance with nearly the same underwater view angle of the camera standalone for friendly use.

Compatible Front Mask

  • ZD Front Mask for HERO12
  • ZD Front Mask for Ace Pro
UCL-G100 ZD Underwater Close-up Lens

Bayonet INON ZD Mount compatible to support friendly and speedy lens exchange underwater. Optional INON ZD Lens Holder can hold the UCL-G100 ZD when the lens is not in use.

Drastically shorten minimum focusing distance with nearly the same underwater view angle of the camera standalone for friendly use.

Compatible Front Mask

  • ZD Front Mask for HERO12
    ZD Front Mask for Ace Pro

page top

[SD Mount]
UCL-G100 SD Underwater Close-up Lens

JAN/EAN code : 4570018120879

UCL-G100 SD Underwater Close-up Lens

Bayonet INON SD Mount compatible to support friendly and speedy lens exchange underwater. Optional INON AD Lens Holder can hold the UCL-G100 SD when the lens is not in use.

Drastically shorten minimum focusing distance with nearly the same underwater view angle of the camera standalone for friendly use.

Compatible Front Mask

  • SD Front Mask for HERO9
  • SD Front Mask for HERO8
  • SD Front Mask for HERO5/6/7
  • SD Front Mask STD
  • SD Mount Cage for HERO3/3+/4
UCL-G100 SD Underwater Close-up Lens

Bayonet INON SD Mount compatible to support friendly and speedy lens exchange underwater. Optional INON AD Lens Holder can hold the UCL-G100 SD when the lens is not in use.

Drastically shorten minimum focusing distance with nearly the same underwater view angle of the camera standalone for friendly use.

Compatible Front Mask

  • SD Front Mask for HERO9
  • SD Front Mask for HERO8
  • SD Front Mask for HERO5/6/7
  • SD Front Mask STD
  • SD Mount Cage for HERO3/3+/4

page top

Features

Easy-to-use All Around Close-up Lens

A close-up lens with a middle magnification among three UCL-G series lenses, providing twice the magnification of the UCL-G165II (scale ratio) to use for macro imaging. This lens significantly shortens the minimum focusing distance while maintaining the same underwater angle of view as the GoPro® alone and easy-to-use all-around close-up lens with deep depth of field among lenses in the same class.

*Depth of field gets shallower with higher magnification due to the nature of close-up lenses.

Angle of view

depth of field

Change FOV Setting for Further Magnification


The distance between two sticks represents a shooting range of the UCL-G100 when GoPro® is set to "WIDE". GoPro® has several field of view settings, and with "Linear" or other narrower angle of view, it is possible to shoot at an even higher magnification. Shooting at a high resolution such as 4K with "1.4x" zoom can enlarge the subject even more with relatively less image quality degradation.

Shooting frame
Video by : Yasushi Setoguchi

Blur-free Focus Stick (PAT.P)

The distance between two sticks represents a shooting range of the UCL-G100 when GoPro® is set to "WIDE". Focus Stick tip represents minimum focusing distance and far end of the depth of field is 8.2cm/3.2in from the tip.
It is easy to take sharp and crispy high magnification close-up video by referring to the Focus Stick and checking the composition on the rear monitor.
The Focus Stick rotates 360° and has clicks every 90°, so it can be instantly flipped up when not in use. Vertical installation is also possible. The Focus Stick body is attached to the lens with retaining screw ring and can be separated from the lens when not necessary.

Close-up device
Shooting scenery
Close-up device

Visually indicates the distance to focus, and can easily fold not to limit camera placement.

The distance between two sticks represents a shooting range of the UCL-G100 when GoPro® is set to "WIDE". Focus Stick tip represents minimum focusing distance and far end of the depth of field is 8.2cm/3.2in from the tip.
It is easy to take sharp and crispy high magnification close-up video by referring to the Focus Stick and checking the composition on the rear monitor.
The Focus Stick rotates 360° and has clicks every 90°, so it can be instantly flipped up when not in use. Vertical installation is also possible. The Focus Stick body is attached to the lens with retaining screw ring and can be separated from the lens when not necessary.

接写装置
Shooting scenery
Close-up device

Visually indicates the distance to focus, and can easily fold not to limit camera placement.

page top

Compatible Accessories

Front Replacement Lens Cap
UCL-G100 ZD
UCL-G100 SD

Front Replacement Lens Cap

Front Replacement Lens Cap
Accessories : Focus Stick for UCL-G100


Front Replacement Lens Cap

Rear Replacement Lens Cap
UCL-G100 ZD


Rear Replacement Lens Cap

Rear Replacement Lens Cap
UCL-G100 SD


Rear Replacement Lens Cap

Front Replacement Lens Cap
UCL-G100 ZD
UCL-G100 SD

Front Replacement Lens Cap

Front Replacement Lens Cap
Accessories : Focus Stick for UCL-G100

Front Replacement Lens Cap

Rear Replacement Lens Cap
UCL-G100 ZD

Rear Replacement Lens Cap

Rear Replacement Lens Cap
UCL-G100 SD

Rear Replacement Lens Cap
page top

Options

ZD Lens Holder M5
UCL-G100 ZD

ZD Lens Holder M5

ZD Lens Holder S
UCL-G100 ZD

ZD Lens Holder S

AD Lens Holder for Float Arm
UCL-G100 SD

AD Lens Holder for Float Arm

AD Lens Holder
UCL-G100 SD

AD Lens Holder

AD Lens Holder Shoe Base
UCL-G100 SD

AD Lens Holder Shoe Base

ZD Male Bayonet for SD Lens
UCL-G100 SD

ZD Male Bayonet for SD Lens
page top

Specifications

  UCL-G100 ZD UCL-G100 SD
Size Lens:
 77mm/3.0in [diameter]
 26.8mm/1.1in [length]
With Focus Stick:
 W172xH91xD95mm/W6.8xH3.6xD3.7in [Focus Stick extended]
 W172xH125xD29mm/W6.8xH4.9xD1.1in [Focus Stick folded]
Lens:
 77mm/3.0in [diameter]
 26.8mm/1.1in [length]
With Focus Stick:
 W172xH91xD95mm/W6.8xH3.6xD3.7in [Focus Stick extended]
 W172xH125xD29mm/W6.8xH4.9xD1.1in [Focus Stick folded]
Weight 180g/6.3oz [lens standalone, air]
49.6g/1.7oz [Focus Stick standalone, air]
106g/3.7oz [with Focus Stick, underwater]
174g/6.1oz [lens standalone, air]
49.6g/1.7oz [Focus Stick standalone, air]
102g/3.6oz [with Focus Stick, underwater]
Mount system INON ZD Mount INON SD Mount
Depth rating 60m / 196.9ft
Body material
/finishing
Corrosion resistant aluminum alloy
rigid black alumite, PC etc.
Lens material
/coating
Optical glass / both side coating
Lens construction 2 groups 2 elements
View angle Approx. 90°[underwater]
Depth of field(*1) 7.0cm/2.8in to 15.2cm/6.0in
Compatible camera HERO4 and later
 Remarks Compatible INON “ZD Front Mask” is required to use the attachment lens. Compatible INON “SD Front Mask” is required to use the attachment lens.

  UCL-G100 ZD UCL-G100 SD
Size Lens:
 77mm/3.0in [diameter]
 26.8mm/1.1in [length]
With Focus Stick:
 W172xH91xD95mm/W6.8xH3.6xD3.7in [Focus Stick extended]
 W172xH125xD29mm/W6.8xH4.9xD1.1in [Focus Stick folded]
Lens:
 77mm/3.0in [diameter]
 26.8mm/1.1in [length]
With Focus Stick:
 W172xH91xD95mm/W6.8xH3.6xD3.7in [Focus Stick extended]
 W172xH125xD29mm/W6.8xH4.9xD1.1in [Focus Stick folded]
Weight 180g/6.3oz [lens standalone, air]
49.6g/1.7oz [Focus Stick standalone, air]
106g/3.7oz [with Focus Stick, underwater]
174g/6.1oz [lens standalone, air]
49.6g/1.7oz [Focus Stick standalone, air]
102g/3.6oz [with Focus Stick, underwater]
Mount system INON ZD Mount INON SD Mount
Depth rating 60m / 196.9ft
Body material
/finishing
Corrosion resistant aluminum alloy
rigid black alumite, PC etc.
Lens material
/coating
Optical glass / both side coating
Lens construction 2 groups 2 elements
View angle Approx. 90°[underwater]
Depth of field(*1) 7.0cm/2.8in to 15.2cm/6.0in
Compatible camera HERO4 and later
 Remarks Compatible INON “ZD Front Mask” is required to use the attachment lens. Compatible INON “SD Front Mask” is required to use the attachment lens.

(*1) Measured DoF from foreground of the lens surface. Divide by 1.33 for visual distance underwater.

page top

Remarks

[When using the UCL-G100]
The UCL-G100 is designed only for underwater use. Using on land creates vignetting.
[When using for GoPro]
Set the camera's field of view (FOV)/Digital Lenses to [Wide] for quality-oriented, or [Linear] for magnification-oriented photography.
When using with HERO11 Black, HERO12 Black and HERO13 Black, shoot in 4:3 or 16:9 aspect ratio as vignetting will occur in 8:7 or [HyperView™] mode which compresses footage in 16:9 aspect ratio by using the full 8:7 sensor.
[SuperView™] mode is not recommended. The SuperView™ mode stretches both ends of the image inside the camera to fit into a 16:9 aspect ratio from originally obtained 4:3 aspect ratio image by the camera sensor. Since the edges of the frame are stretched horizontally, using an attachment lens further stretches the edges of the frame, resulting in an unnatural image.
Set the camera's image stabilization (HyperSmooth) to [Standard], [High], or [On]. Setting to [Off] will cause vignetting in image corners, and [Boost] will crop the image significantly.
The FOV/Digital Lenses setting [Wide] in Photo mode causes vignetting in image corners.

page top

Sample Movie

092
Video by Toru Kasuya
UFL-G140 SD
UCL-G100 SD / UCL-G55 SD
090
Video by Hirokazu Natsui
UCL-G100 SD
LE600h-S
089
Video by Hideki Abe
UCL-G100 SD
LF2400h-EW
088
Video by Hideki Abe
UCL-G100 SD
LF2400h-EW
085
Video by Yasushi Setoguchi
UCL-G100 SD
UCL-G55 SD

*GoPro and HERO are trademarks or registered trademarks of GoPro Inc.

*Insta360 is a trademark or registered trademark of Arashi Vison Inc.

*Specifications are subject to change without notice.
