UWL-95S XD

UWL-95S XD Wide Conversion Lens

JAN/EAN code : 4570018120268

UWL-95S XD Wide Conversion Lens






XD Mount/Dual use land/underwater-Focus ON Lens-AR coating-Optional Dome Lens-U/W FOV Max.95°
UWL-95S XD Wide Conversion Lens
XD Mount/Dual use land/underwater-Focus ON Lens-AR coating-Optional Dome Lens-U/W FOV Max.95°



XDマウント

ハウジングへのセットイメージ

ハウジングセットイメージ

"XD Mount" makes it easy
The newly developed " XD Mount " enables one-touch lens attachment and removal. The "XD Mount" has high durability, thin design not to spoil optical performance of the lens, lock function to prevent slipping off. Using the " XD Mount " on housing enables you to attach and remove a lens at once.


Compact and handy
Compact size with 90mm outer diameter and 48.5mm length makes it easy to carry around. Thanks to the thin "XD Mount" design which does not sacrifice lens optical performance, the overall set size remains compact when attached on a housing.

Dual use land/underwater
Maximum view angle underwater is 95° which gets widen to 159° when using on land providing fisheye images without complicated and expensive gears.


Olympus TG-6
Without lens UWL-95S XD
Without lens UWL-95S XD

Without lens UWL-95S XD
Without lens UWL-95S XD

ドームレンズユニット装着図


Super wide option
Optional Dome Lens Unit IIIA, Dome Lens Unit IIIG widens original view angle to approx. 141°.

Olympus TG-6
Without lens
UWL-95S XD UWL-95S XD + Dome Lens Unit IIIG
Without lens UWL-95S XD UWL-95S XD+
Dome Lens Unit IIIG

Without lens
UWL-95S XD UWL-95S XD + Dome Lens Unit IIIG
Without lens UWL-95S XD UWL-95S XD+
Dome Lens Unit IIIG

click here for detail of Dome Lens Unit III

Newly designed optics provides quality underwater images
Totally renewed optical design effectively suppresses flare/ghost even in backlit condition to provide sharp and high quality image together with optimal lens positioning relative to camera master lens.

Minimum Focusing Distance 0 cm
A subject just in front of the lens or distant seascape never get out of focus. The lens won’t limit shooting distance.

Usable with All Zoom Range
Unlike conventional wide conversion lenses, which are recommended to be used only at zoom wide end as zooming results in poor image quality in peripheral areas, this lens manages to keep high quality image regardless of camera's zoom setting.

Optical Anti-Reflection Coating (AR-Coating)
All component lenses are finished with optical anti-reflective coating, which thoroughly suppresses flare and ghosting providing stable image quality in backlit scenes where flare and ghosting are likely to occur.


click here for detail of Dome Lens Unit III
"XD Mount" makes it easy
The newly developed " XD Mount " enables one-touch lens attachment and removal. The " XD Mount " has high durability, thin design not to spoil optical performance of the lens, lock function to prevent slipping off. Using the " XD Mount " on housing enables you to attach and remove a lens at once.

XD Mount


Compact and handy
Compact size with 90mm outer diameter and 48.5mm length makes it easy to carry around. Thanks to the thin "XD Mount" design which does not sacrifice lens optical performance, the overall set size remains compact when attached on a housing.

Setup Images

Setup Images


Dual use land/underwater
Maximum view angle underwater is 95 ° which gets widen to 159 ° when using on land providing fisheye images without complicated and expensive gears.
Olympus TG-6
Without lens UWL-95S XD
Without lens UWL-95S XD

Without lens UWL-95S XD
Without lens UWL-95S XD


Super wide option
Optional Dome Lens Unit IIIA, Dome Lens Unit IIIG widens original view angle to approx. 141 °.
ドームレンズユニットIII装着図

Olympus TG-6
Without lens UWL-95S XD UWL-95S XD + Dome Lens Unit IIIG
Without lens UWL-95S XD UWL-95S XD+
Dome Lens Unit IIIG


Without lens UWL-95S XD UWL-95S XD + Dome Lens Unit IIIG
Without lens UWL-95S XD UWL-95S XD+
Dome Lens Unit IIIG
For detail of the Dome Lens Unit III, click here


Newly designed optics provides quality underwater images
Totally renewed optical design effectively suppresses flare/ghost even in backlit condition to provide sharp and high quality image together with optimal lens positioning relative to camera master lens.

Minimum Focusing Distance 0 cm
A subject just in front of the lens or distant seascape never get out of focus. The lens won’t limit shooting distance.

Usable with All Zoom Range
Unlike conventional wide conversion lenses, which are recommended to be used only at zoom wide end as zooming results in poor image quality in peripheral areas, this lens manages to keep high quality image regardless of camera's zoom setting.

Optical Anti-Reflection Coating (AR-Coating)
All component lenses are finished with optical anti-reflective coating, which thoroughly suppresses flare and ghosting providing stable image quality in backlit scenes where flare and ghosting are likely to occur.


For confirmed usable camera/housing, click here
SONY[URX-100A]
SONY[URX-100A]
Olympus[PT-059]
Olympus[PT-059]
*Optional “XD Mount”is required.
page top

Interchangeable Lens Mount
Replacing the original lens mount with an optional lens mount can convert lens type. Below options are available for type conversion.
“M52 Screw Ring for UWL-95S”
“M67 Screw Ring for UWL-95S”
