UCL-165 XD

UCL-165 XD Close-up Lens

JAN/EAN code : 4570018120275

*Optional “XD Mount” is required.

+6 diopter

XD Mount" for one-touch lens attachment and removal
The newly developed "XD Mount" enables one-touch lens attachment and removal. The "XD Mount" on a lens provides high durability, thin design without compromising lens optical performance and speedy lens attachment/removal in combination with XD Mount on housing side which has reasonable price and anti-slip lock function.


A high magnification close-up lens providing 165mm focal length (+6 diopter) where 165mm shooting distance from lens surface when camera’s focus position is set to infinity. Using minimum focusing distance will shorten minimum focus distance allowing you to get closer to a subject enabling high magnification close-up photography.

Dual use underwater/land and usable with all zoom range. Even at same shooting distance, it is easy to capture a subject at desired size by adjusting zoom setting.

CANON RF100mm F2.8L MACRO IS USM
Without close-up lens
Without close-up lens
With UCL-165 XD
With UCL-165 XD
Without close-up lens
Without close-up lens
With UCL-165 XD
With UCL-165 XD

The lens construction is 2 elements in 2 groups with high quality optical glass with inner coating to suppress optical aberrations more effectively.

INON unique bayonet mount “XD Mount

page top

Sample movie

081

Video by Korechika Yano
UWL-95S / UCL-67
UCL-90 / UCL-165
UCL-330 / UFL-M150 ZM80
079

Video by Toru Kasuya
UFL-M150 ZM80/UWL-95S XD
UCL-330/UCL-165 XD
Dome Lens Unit IIIG
078

Video by Korechika Yano
UFL-M150 ZM80/UWL-95S XD
UCL-330/UCL-165 XD
Dome Lens Unit IIIG
072

Video by Korechika Yano
UCL-165M67
LF2400h-EW

050

Video by Korechika Yano
UCL-90 M67/UCL-165M67
UFL-M150 ZM80/UCL-330
LF2400h-EW
049

Video by Korechika Yano
UCL-90 M67/UCL-165M67
UCL-330
LF3100-EW
048

Video by Korechika Yano
UCL-90 M67/UCL-165M67
LF3100-EW

047

Video by Korechika Yano
UCL-90 M67/UCL-165M67
UCL-330
LF3100-EW
042

Video by Korechika Yano
UCL-90 M67/UCL-165M67


041

Video by Korechika Yano
UCL-90 M67/UCL-165M67
UCL-330

033

Video by Korechika Yano
UCL-165LD


031

Video by Korechika Yano
UCL-165M67/UCL-100LD
LF2700-W

028

Video by Korechika Yano
UCL-165LD/UFL-M150 ZM80
UCL-330

024

Video by Korechika Yano
UCL-165LD/UFL-M150 ZM80
UCL-330/UCL-100LD

081

Video by Korechika Yano
UWL-95S / UCL-67
UCL-90 / UCL-165
UCL-330 / UFL-M150 ZM80
079

Video by Toru Kasuya
UFL-M150 ZM80/UWL-95S XD
UCL-330/UCL-165 XD
Dome Lens Unit IIIG
078

Video by Korechika Yano
UFL-M150 ZM80/UWL-95S XD
UCL-330/UCL-165 XD
Dome Lens Unit IIIG
072

Video by Korechika Yano
UCL-165M67
LF2400h-EW
050

Video by Korechika Yano
UCL-90 M67/UCL-165M67
UFL-M150 ZM80/UCL-330
LF2400h-EW
049

Video by Korechika Yano
UCL-90 M67/UCL-165M67
UCL-330
LF3100-EW
048

Video by Korechika Yano
UCL-90 M67/UCL-165M67
LF3100-EW
047

Video by Korechika Yano
UCL-90 M67/UCL-165M67
UCL-330
LF3100-EW
042

Video by Korechika Yano
UCL-90 M67/UCL-165M67
041

Video by Korechika Yano
UCL-90 M67/UCL-165M67
UCL-330
033

Video by Korechika Yano
UCL-165LD
031

Video by Korechika Yano
UCL-165M67/UCL-100LD
LF2700-W
028

Video by Korechika Yano
UCL-165LD/UFL-M150 ZM80
UCL-330
024

Video by Korechika Yano
UCL-165LD/UFL-M150 ZM80
UCL-330/UCL-100LD

Sample images at telephoto end

クリックすると拡大します
UCL-165M67 x 2
Zoom: telephoto end
Working distance: 57mm / 2.2in
Shooting distance: 26 x 22mm (1.0 x 0.8in)
クリックすると拡大します
UCL-165M67 + UCL-330
Zoom: telephoto end
Working distance: 66mm / 2.6in
Shooting distance: 30 x 23mm (1.2 x 0.9in)
クリックすると拡大します
UCL-165M67 x 1
Zoom: telephoto end
Working distance: 101mm / 4.0in
Shooting distance: 37 x 28mm (1.5 x 1.1in)
クリックすると拡大します
UCL-330 x 2
Zoom: telephoto end
Working distance: 89mm / 3.5in
Shooting distance: 38 x 29mm (1.5 x 1.1in)
クリックすると拡大します
UCL-330 x 1
Zoom: telephoto end
Working distance: 139mm / 5.5in
Shooting distance: 49 x 37mm (1.9 x 1.5in)
クリックすると拡大します
without close-up lens
Zoom: telephoto end
Working distance: 218mm / 8.6in
Shooting distance: 73 x 55mm (2.9 x 2.2in)

Sample images at wide end

クリックすると拡大します
UCL-165M67
Zoom: wide end
Working distance: 70mm / 2.8in
Shooting distance: 78 x 58mm (3.1 x 2.3n)
クリックすると拡大します
UCL-330
Zoom: wide end
Working distance: 78mm / 3.1in
Shooting distance: 92 x 69mm (3.6 x 2.7in)
クリックすると拡大します
without close-up lens
Zoom: wide end
Working distance: 113mm / 4.4in
Shooting distance: 112 x 84mm (4.4 x 3.3in)

[When using a close-up lens]

*Depending on housing, shooting distance, angle of view etc., the lens may block the built-in flash light from illuminating the entire image. In such cases it is recommended to shoot with an external strobe or flashlight.

*A close-up lens provides maximum magnification at zoom telephoto end.

*Generally, a close-up lens shortens the camera’s close focusing distance. With this product, you can place your camera closer to a subject, achieving a larger image. On the other hand, depending on zoom or aperture setting, it may be more difficult to obtain complete depth of field on a distant subject.

*Stacking multiple lenses may cause vignetting at zoom wide end. As you stack more lens, focusing distance gets short and depth of field gets shallow as well.
