INON

UW Variable Red Filter M67

 [Discontinued]

UW Variable Red Filter M67

Compatible Mount
28LD Mount

Maximum filter strength (left) to minimum filter strength (right)

Maximum filter strength (left) to minimum filter strength (right)



The INON UW Variable Red Filter M67 is a variable color correction filter to suppress blue cast when photographing/filming without light source.

The combination of two polarizing filters reduces blue and green wave length to suppress blue cast underwater.

Turning front polarizing filter provides wide and seamless adjustment from least to maximum effect where almost all blue and green wavelengths are cut. You can adjust the filter strength depending on depth or water condition like setting minimum effect near the bright surface while using stronger filter setting at depth with insufficient orange or yellow wavelength.

The product is designed to set minimal filter strength to use with external lighting device such as a strobe or LED light. For example, shooting wide angle image with ambient light and stronger filter setting, and use minimum filter strength for a macro imaging to use an LED torch. No need to worry to attach or remove the filter.
Two filters are combined with simple yet reliable bayonet system to separate underwater to escape trapped bubbles in between or clean filters after using easily.

The filter is equipped with highly versatile screw type "M67 Mount".


(*) When reducing blue/green wavelength significantly with this product and using external strobe/light will have strong reddish portion lit by the external strobe/light. If this is the case, set minimum filter strength or remove this product.



(*) Depending on combined camera/housing, an image may have vignetting. If this happens, zoom in until no vignetting is observed.



(*) The "UW Variable Red Filter M67" is patent pending.

Directly screwed in housing portThe UW Variable Red Filter M67 installed directly on housing port

The UW Variable Red Filter M67 installed directly on housing port

The UW Variable Red Filter M67 installed via Step-up Ring 52-67

The UW Variable Red Filter M67 installed via Step-up Ring 52-67

Size

83.6mm / 3.3in (Diameter), 20mm / 3.3in (Length)

Weight

[air] 77.6g / 2.7oz
[underwater] Approx. 40g / 1.4oz

Material

Polarizing glass, Corrosion resistant aluminum alloy, Poly carbonate

Compatible Options

Step-up Ring 52-67

Step-up Ring 52-67

UCL-330 Neoprene Carry Pouch

UCL-330 Neoprene Carry Pouch

Sample images

UW Variable Red Filter M67 Sample image
Left: Without filter / Right: With UW Variable Red Filter M67
Sony RX100M5/MPK-URX100A, at 2.5m depth
UW Variable Red Filter M67 Sample image
Left: Without filter / Right: With UW Variable Red Filter M67
Sony RX100M5/MPK-URX100A, at 6m depth

Sample movie

Sample Movie
UW Variable Red Filter M67 comparison
(C)Korechika Yano
